Product Classification
56A Series Fuel Dispenser
56A Multi-Nozzle Fuel Dispenser *56A series classic appearance, 1-8 nozzles can meet different customer needs *Black appearance classic design, rich configuration to provide more choices *Strong sheet metal, durable corrosion resistance and extended service life
Product Classification:
56A Series Fuel Dispenser
Product Description：
56A Multi-Nozzle Fuel Dispenser
*56A series classic appearance, 1-8 nozzles can meet different customer needs
*Black appearance classic design, rich configuration to provide more choices
*Strong sheet metal, durable corrosion resistance and extended service life
Parameters:
Accuracy:±0.30%
Min. Measured:5L
Noise:≤80dB(A)
Imported Vacuum Degree:≥54kPa
Ambient Temperature: -25℃- 55℃
Relative Humidity:≤95%
Applicable Media:Gasoline, diesel and kerosene
Display:775 system
Unit price range:0-999.99 (Decimal point adjustable)
Single Counting Range:Volume: 0.00-99999.00L / Amount: 0.00-99999.00
Cumulative Count Range:Volume: 0-42949672.95L / Amount: 0-42949672.95
Power Supply:AC220V/380V
Motor Rated Power:0.75kw/1.1kw
|
Standard Configuration |
Optional Configuration |
|
Suction or Submersible Type |
Built-in Receipt Printer |
|
380V/220V Ex-proof Motor |
Tokheim Pump and Meter |
|
Standard Flow Rate 50L/min |
Breakaway Valve |
|
775 LCD Display System |
Short Hose Assembly |
|
Emergency Stop Button |
High Flow Rate 75L/min |
|
Mechanical Totalizer |
Metal Keypad |
|
Cold Plate Metal Shell |
Aluminum Nozzle Holder |
|
Plastic Keypad |
Customize Logo and Painting Color |
|
Stainless Steel Hose Hook |
|
